ACV Lasiantenni 2x Vahvistin

Note:

black: +12V antenna remote
GND ground strap: GND clamp 31 car body direct

status LED: green

GND ground strap: installation with optimal ground connection
GND ground strap: must not be extendet or shorten

mounting horizontal
clean adhesive surface with suitable means to remove dust and grease


Use case:

AM/FM antenna for mounting in all vehicles / motorhomes / caravans / commercial vehicles on all smooth surfaces such as wood / glass / plastic / GRP internally

Reception Mode:
AM/FM

Installation:
antenna self-adhesive with GND cable

behind or on non-metallic trim internal
glass adhesive antenna internal

recommended:
windscreen horizontal behind rear view mirror
distance min. 4 cm from car body

Dimensions:
30 cm x 6,4 cm x 1,6 mm

Connections:
AM/FM: DIN(m)
antenna remote: loose wire

Cable:
length: 240 cm
imedance: 150 Ohm
capacity: 85 pF/m

Frequency range:
AM: 150 kHz - 1710 kHz
FM:  87,5 MHz - 108 MHz

Power supply:
AM/FM: +12V external
