ACV Bullet-liitin naaras Punainen 100 Kpl

Female bullet disconnector red

Easy-Entry series

Vinyl PVC female bullet disconnector(f) 0,5 mm² - 1,5 mm² / 3,9 mm² brass electro tin plated

UL-listed male bullet disconnectors with high tensile strength and excellent conductivity thanks to the use of brass for permanently corrosion-protected separable plug connections of cables in the automotive industry, in the agricultural machinery sector and in the commercial vehicle sector.

The Easy-Entry design prevents the individual strands from splicing when the cable is inserted to make the installation quick, safe and easy.

Note:

additionally secure by using suitable means the plug connection against loosening due to vibrations is recommend

Use case:

cable diameter: 0,5 mm² - 1,5 mm²
cable diameter: 22 - 16 AWG

Technical data:

length: 24,5 mm
diameter socket: 3,9 mm²
diameter cable entry: 3,9 mm² max.
diameter strand: 1,7 mm² max.

material: brass electro tin plated
insulation: vinyl PVC
operating temperature: -10 °C - 75 °C max.
electrical current: 300V max.
electrical rating: 10A max.

REACH and RoHS compliant
UL-listed

Content:

100 pieces
