ACV Ford ISO

Note:

connector: 24 Pin Ford
connector: 8 Pin Amp Ford > RCA(m)

vehicles with/without OEM amplified system

blue/white2 x: +12V Amp remote connection with 1.5 kOhm resistor scope of delivery
pink: telephone mute
brown: telephone mute
blue: antenna remote
orange/white: +12V switched dimmer
orange/black: ground switched dimmer

Vehicle application:

Ford
Ford Crown Victoria 2003 - 2011
Ford Ecoline Van 2009 - 2016
Ford Escape 2005 -2012
Ford Excursion 2005
Ford Expedition 2003 - 2014
Ford Explorer 2006 - 2010
Ford F-150 2004 - 2008
Ford F-250 2005 - 2016
Ford F-350 2005 - 2016
Ford F-450 2005 - 2016
Ford Five Hundred 2005 - 2007
Ford Freestar 2004 - 2007
Ford Freestyle 2005 - 2007
Ford Mustang 2004 -2009
Ford Super Duty 2005 - 2012
Ford Taurus X 2008 - 2009
Ford Thunderbird 2004 - 2005

Lincoln
Lincoln Navigator 2003 - 2006
Lincoln Town Car 2003 - 2011

Mazda
Mazda Tribute 2008 - 2011

Mercury
Mercury Grand Marquis 2003 - 2010
Mercury Marauder 2003 - 2006
Mercury Mariner 2005 - 2011
Mercury Milan 2006 - 2009
Mercury Monterey 2004 - 2006
Mercury Mountaineer 2006 - 2010
