ACV Kaiutinterminaali 4-nap

Bi-Wiring speaker terminal for speaker- or subwoofer enclosure construction.

For connecting speaker cables with 4 mm banana plugs.
Alternatively as screw terminal for direct connection of speaker cables up to 4 mm² to minimise contact resistance.

Recessed design to avoid transport damage to the connections.
Large contact surface to ensure air-tightness.
Gold-plated connections.

For the following applications:

speaker enclosure construction
subwoofer enclosure construction

Technical data:

material: ABS plastic
dimensions: 120 mm x 95 mm
mounting dimensions: 95 mm x 75 mm
connection external: plug-in connection Ø 5 mm screw connection Ø 5 mm
connection inside: flat connector 5,2 mm /  flat solder connector

Optional:

Banana plug 1 x red/1 x black 4 mm²>6mm² single plug: 30.4070-01
Banana plug 1 x red/1 x black 4 mm²>6mm² double plug: 30.4070-02
